Neptune CS2-75-PVC-NL-AWWA Bronze Corporation Stop, 3/4" NPT, CPVC Quill, No Lead,Meets AWWA Standards

Neptune

MSRP: $286.00
$257.40
(You save $28.60 )
(No reviews yet) Write a Review
SKU:
CS2-75-PVC-NL-AWWA
Weight:
3.00 LBS
Shipping:
Calculated at Checkout
Adding to cart… The item has been added


Neptune Corporation Stops with injection quills are used for injecting chemicals pumped by metering pumps into tanks, mains, cooling towers and process systems. Neptune injection quill extends into the center of the stream providing more rapid uniform dispersion of injected chemical.

A Neptune Corp Stop can be mounted to a “hot tap” which is installed without draining the system. Corporation Stop allows injection quill to be inserted or removed with having to drain the system or shut down the operation.

Simply retract the quill by loosening the compression fitting and close the valve after the end has cleared the ball valve. A safety chain is provided to prevent the quill from shooting all the way out of the valve should your hand slip or the compression fitting becomes loose.



Model Neptune CS2-75-PVC-NL-AWWA

3/4" Process Connection

CPVC Injection Quill

125 PSI Max

100 F Temperature Max

Bronze Lead Free Corp Stop

Meets AWWA Standards




Dimension:

A = 3/4" NPT

B = 7-3/4"

C = 5-1/4"

D = 2"







Note: Special Length Available Up To 24" Max. Call For Quote 1 916 315-2691



This model replaces Neptune CS2-75-PVC Corporation Stop
