Classic Series Double Head Fixed Pumps

When your application demands a higher output than the Classic Single Head Pump can provide - particularly in 25 psi setups for large commercial swimming pools - Stenner Classic Double Head Fixed Pump is the ideal upgrade. Like other models in the Classic Series, this pump precisely doses solutions such as sodium hypochlorite, acid, polyphosphates, and biocides, serving a wide range of water treatment processes including disinfection, pH regulation, corrosion and scale prevention, oxidation, and sanitization.

Engineered for versatility, it’s also commonly used in water and wastewater treatment facilities, where it can simultaneously inject two compatible chemicals at the same ratio. The Classic Series Double Head Fixed model shares the same durable design as the single head version, enhanced with an additional pump head to double its capacity. Operating at a consistent 100% fixed flow rate, it can also be integrated with an ORP controller for precise automated output management.

Sidebar Sidebar Sidebar
  • Stenner 170 Fixed, Low Pressure Pump, 170DMP

    Stenner

    Stenner 170 Fixed, Low Pressure Pump, 170DMP

    CFA291327,44 - CFA311516,36
    Fixed flow rate output Self-priming, does not lose prime or vapor lock Pumps off-gassing solutions and can run dry 3-point roller design assists with anti-siphon Tube replacement without tools Output reproducibility Tube lubrication not required Foot...
    CFA291327,44 - CFA311516,36

  • Stenner 170 Fixed, High Pressure Pump, 170DMPHP

    Stenner

    Stenner 170 Fixed, High Pressure Pump, 170DMPHP

    CFA300393,87 - CFA333786,11
    Fixed flow rate output Self-priming, does not lose prime or vapor lock Pumps off-gassing solutions and can run dry 3-point roller design assists with anti-siphon Tube replacement without tools Output reproducibility Tube lubrication not required Foot...
    CFA300393,87 - CFA333786,11

  • Stenner 100 Fixed, Low Pressure Pump, 100DMP

    Stenner

    Stenner 100 Fixed, Low Pressure Pump, 100DMP

    CFA277455,29 - CFA311516,36
    Fixed flow rate output Self-priming, does not lose prime or vapor lock Pumps off-gassing solutions and can run dry 3-point roller design assists with anti-siphon Tube replacement without tools Output reproducibility Tube lubrication not required Foot...
    CFA277455,29 - CFA311516,36

  • Stenner 100 Fixed, High Pressure Pump, 100DMPHP

    Stenner

    Stenner 100 Fixed, High Pressure Pump, 100DMPHP

    CFA286088,22 - CFA333792,30
    Fixed flow rate output Self-priming, does not lose prime or vapor lock Pumps off-gassing solutions and can run dry 3-point roller design assists with anti-siphon Tube replacement without tools Output reproducibility Tube lubrication not required Foot...
    CFA286088,22 - CFA333792,30

Features:

  • Interchangeable pump heads and tubes to convert one model to another without having to purchase a new pump.
  • Tube replacement without tools with the patented QuickPro pump head.
  • The pump is built with three detachable components; the motor and two pump head that can be separated without tools.

Technical Specifications:

  • Reproducibility: +/- 2%
  • Maximum Working Pressure: 25 psi (1.7 bar), 100 psi (6.9 bar)
  • Maximum Operating Temperature: 125°F (52°C)
  • Maximum Suction Lift: 25 ft (7.6 m) vertical lift, based on water
  • Motor Type: 1/30 HP, shaded pole, class B
  • Shaft RPM (average maximum): 26 or 44
  • Duty Cycle: Continuous
  • Maximum Viscosity: 1500 Centipoise
  • Cord Length: 6 ft (1.8 m)
  • Classification: Indoor and suitable for Outdoor when installed with a Stenner Rain Roof part number MP90000
