CARLON Model SCBV Slow Closing Ball Valve

No reviews yet
SKU: SCBV Series
Weight: 1.10 LBS
Shipping: Calculated at Checkout
$473.00 - $1,148.00
icon Share icon Share
  • product-security-image-1.jpg
  • product-security-image-2.jpg
  • product-security-image-3.jpg
  • product-security-image-4.jpg

You know the damaging effects of water hammer in your system. Leaking, noisy pipes and broken meters are commonplace. Want a reliable, economical solution? Carlon’s 2-way full port ball valves to the rescue  featuring electric actuators and available in ¾"– 2” sizes.

Why choose a 2-way full port slow closing ball valve over a standard valve? It’s all about the value because only slow closing valves should be used on water lines reducing water hammer… Specify Carlon’s 2-way full port slow closing ball valves and achieve outstanding performance.

Specifications

  • Description: 2-way stainless steel full port ball valve with electric actuator.
  • Features: Water hammer free design.
    Opens & closes at same speed with low noise
  • Materials: 304 Stainless steel body with EPDM Seals (NSF61-G Listed)
  • Electrical Connection: 19” 3-wire cable
  • Ambient Temperature: Maximum 122° F
  • Media Temperature: Maximum 284° F
  • Pressure Range: 1.5 – 145 psi
  • Operating Voltage: 120 VAC Standard
  • Protection Class: IP 65 PPO Housing

Downloads

SCBV Datasheet

SCBV Manual
