Walchem EWP-035BVC07A-USL Pump, 0.6 GPH, 150 PSI

Walchem EWP-035BVC07A-USL

• 0.6 GPH
• 150 PSI
• PVC Pump Head
• Ceramic Balls
• FKM (Viton) Valve Seat / O-Ring
• PTFE Gasket
• PCTFE (Bonded to EPDM) Diaphragm
• 3/8" O.D. x 1/4" I.D. Tubing

Engineered for both reliability and versatility, the EWP-L features external analog and simple digital pulse input control as well as manual control with an 1800:1 turndown ratio. Its high-speed 360 strokes-per-minute operation ensures consistent performance, while its robust priming capability and durable construction make it the optimal choice for any cost-effective, high-precision chemical injection applications.

Simple operation and adjustment with two control knobs, flowrates up to 6.7 GPH (25 l/h) and pressure capability to 175 psi (12 bar) enable the EWP-L to easily fit into most applications.

Flexible Installation

An optional quick-access mounting base* enables the EWP-L to be easily wall mounted or quickly removed from an installation without the need for tools.

*Mounting base (EP1015) sold separately

Rugged Housing

The EWP Series pumps are sealed and rated to an IP66 protection class (water and dust-proof) even without the chemical splash guard*.

*Splash guard cover (EP1014) sold separately
