Advantage Controls AWR Series Water Meters, Cold Water Meters, 105°F Max

Series AWM contacting head water meters provide an electrical dry contact out for proportional control when used with the appropriately optioned controller or pump based on water flow.
Constructed to meet or exceed all sections of AWWA Standard C-708 the AWM series meters have bronze bodies with durable synthetic polymer measuring chambers.
The Multi-Jet chamber assures accuracy over a wide flow range with little head pressure loss. Measurement surfaces are non-wear, providing sustained accuracy despite the presence of small impurities in the water.

Features:

• Meets AWWA Standards
• Multi-Jet Design
• Bronze Body
• Registers Velocity and Totalized Flow
• Low Cost
• Includes Couplings

Specification:

• Pipe Size: 2”, 3", 4"
• Gallons per Contact: 100 GPC
• Pressure: 230 PSI Max
• Flow Range: 2-400GPM, 3-550 GPM, 5-1,250GPM
• Shipping Wt. (lbs): 30, 38, 45
