Stenner S10P Series Pumps

The S10P Series is a peristaltic metering pump activated by a water meter, control valve, flow switch or any control equipment that responds to water flow. The control equipment is wired to the pump input terminals to accept a dry contact or 12-24 VAC/VDC signal. The pump runs at a set time, a set speed or a set flow rate output according to the mode of operation selected. The flow rate outputs are up to 30 gallons per day at 100 psi maximum. The functions are easy to program on the six-button control pad with a backlit LCD window.

Sidebar Sidebar Sidebar
  • sale
    Stenner Pump S10P Series Stenner Pump S10P Display View

    Stenner

    Stenner S10P Series Peristaltic Metering Pump

    د.إ4,850.58
    د.إ3,393.94
    Stenner peristaltic metering pumps S10P flow activated variable speed The S10P Series is a peristaltic metering pump activated by a water meter, control valve, flow switch or any control equipment that responds to water flow. The control equipment is...
    د.إ4,850.58
    د.إ3,393.94

    Quick Add
Compare 0

Modes of Operation:

  • 10 PPG MODE
  • FLOW SWITCH MODE
  • SECONDS MODE
  • AUXILIARY MODE

Technical Specifications:

  • Flow Rate Output Control: Six button control panel with LCD display
  • Reproducibility: +/- 2%
  • Maximum Working Pressure: 100 psi (6.9 bar)
  • Maximum Operating Temperature: 104°F (40°C)
  • Maximum Suction Lift: 25 ft (7.6 m) vertical lift, based on water
  • Motor Type: Brushless DC motor
  • Shaft RPM (average maximum): 45
  • Duty Cycle: Continuous
  • Maximum Viscosity: 1500 Centipoise
  • Motor Voltage (Amp Draw): 120V 60Hz 1PH (0.6)
  • Power Cord Type: 120V 60Hz SJTOWA
  • Power Cord Plug End: 120V 60 Hz 5-15P
  • Power Cord Length: 6 ft (1.8 m)
  • Classification: Indoor / Outdoor

Materials of Construction:

  • All Housings: Polycarbonate
  • Pump Tube & Check Valve Duckbill: Santoprene®* (FDA approved)
  • Pump Head Rollers: Polyethylene
  • Suction/Discharge Line, and Ferrules: Polyethylene (FDA approved)
  • Tube & Injection Fittings: PVC or Polypropylene (both NSF listed)
  • Connecting Nuts: PVC or Polypropylene (both NSF listed)
  • Suction Line Strainer and Cap: PVC or Polypropylene (both NSF listed); ceramic weight
  • All Fasteners: Stainless steel
  • Pump Head Latches: Polypropylene
  • Leak Detect Components: Hastelloy®**
