Eno Scientific Well Watch Level Sensor 670 and 670B with Battery Module

WELL WATCH 670 LEVEL SENSOR

Integrating a water level indicator into your existing Telemetry/SCADA system has never been easier. The Well Watch 670 utilizes low frequency sound waves to provide continuously updated, accurate levels from on top of the well.

The NEW Well Watch 670B is a battery powered sonic water level indicator for off grid or power sensitive applications. The upgraded version of our popular Well Watch 670 now allows you to install in minutes without worrying about hardwiring to an external power source. The easily accessible batteries are rechargeable using the optional Battery Charger or by adding our 10W Solar Panel.

• New Battery Powered Option
• New Optional Solar Panel
• Complete data with easy acquisition
• No proprietary software or monthly fees
• Real time well levels (static, drawdown and recovery)
• Enables well management and control capabilities
• Comply with State and Local usage regulations
• Protect the investment in well and pump equipment
• Built in alarm capability in case of emergencies

The Well Watch eliminates the need to lower anything into the well, such as intrusive water tapes, bubblers or transducers. These methods open your well to contamination issues and tend to get stuck in the pump wiring resulting in an expensive, time-consuming fix.

Each Well Watch can measure from 10 to 7000ft, no need for customized lengths. Apply in wells from 1/2″ up to 10″ in diameter with submersible pumps installed or just bare monitoring wells. For wells larger than 10″ we suggest stepping up to the commercial grade Well Watch 700.

The Well Watch 670 was designed for seamless telemetry connectivity through RS485 (Modbus), RS232, 4-20mA or 0-5V outputs. This ensures you the ability to communicate with your existing remote monitoring system, or we can design a system for you, giving you the ability to view your well levels from any computer or iPhone. For standalone applications, you can utilize the sensor’s built in data logger which is capable of storing 25 million time/date stamped log points. The data is stored in a .txt format that can be viewed/graphed in a program of the user’s choice. Each unit can operate on AC/DC power or optional 10W or 30W solar panel kits for off grid or power sensitive applications.

MEASUREMENT:

• Units - English (ft & in) or Metric
• Resolution - .05 ft (1 cm)
• Accuracy - .1 ft (3 cm)
• Range - 10 to 7000 ft (3 to 2100M)
• Update time - ~1 sec @ 500 ft (150M)

LOGGING:

• Extended Memory - 2GB nonvolatile flash memory for 25 million data points
• Automatic Logging Rates - 1 sec to 60 minutes per sample

POWER:

• External Power - 6.5 to 12VDC at 80ma max.
  Do not exceed 16V.
• Real Time Clock - Li Ion 3V battery CR2032

ENVIRONMENTAL:

• Temperature - -10 to 110 F (-20 to 45 C)
• Humidity - 10 to 90% non-condensing

PHYSICAL:

• Meter Dimensions - 8.25 x 3.5 x 3.5″
• Probe Tip Dimensions - 1/2″, 3/4″ and 1″ MPT

FEATURES:

• Display - 2 x 16 character LCD
• Internal temperature compensation

INPUT/OUTPUT:

• RS232
• RS485 (Modbus)
• 4-20mA output
• 0-5V Analog output
• 5V Alarm output
• USB


Included with Well Watch 670 kit:

• Well Watch Sensor
• Clear Display Cover
• Quick Start Guide
• 3 Nozzles, 1/2", 3/4", 1"
• Microphone Extension Tube
• A/C Power Adaptor
• USB Cable
• 1 Year Warranty

Downloads

670 Level Indicator Product Sheet
