DESCRIPTION
Wetted materials of construction are ABS plastic, with 316 Stainless Steel electrodes. An integral temperature element provides for automatic temperature compensation on both the CSATC and CSAR. The thermowell containing the temperature sensing element in its tip is exposed directly to the fluid stream, assuring rapid response for maximum accuracy.
Potted construction ensures sensor reliability and long service life.
The sensor constant is 1.0. The ranges that can be achieved with these sensors are dependent on the model and range of instrument — up to 20,000 µS/ppm is the normal maximum range of use.
FEATURES
SPECIFICATIONS
| Maximum Pressure/ Temperature Ratings: 75 psi/5,2 bar at 60°C/140°F |
| Wetted Materials: FDA Approved Insulator ABS Electrodes 316 Stainless Steel |
| Temperature Compensation CSA: None CSATC: 10 KΩ @ 25ºC/77°F CSAR: 1000 Ω RTD |
| Connections: 3/4” NPT compatible with BSP Process 3/4” MNPT Electrical Plain tinned wire ends, 22-24 gauge |
| Sensor Constant: Model Range Constant All 0-10 to 0-20,000 µS/ppm 1.0* |
