Technical Specifications:
- Flow Rate Output Control: External dial ring
- Reproducibility: + / – 2%
- Maximum Working Pressure: 25 psi (1.7 bar), 100 psi (6.9 bar)
- Maximum Operating Temperature: 125°F (52°C)
- Maximum Suction Lift: 25 ft (7.6 m) vertical lift, based on water
- Motor Type: 1/30 HP, shaded pole, class B
- Shaft RPM (average maximum): 26 or 44
- Duty Cycle: Continuous
- Maximum Viscosity: 1500 Centipoise
- Motor Voltage (Amp Draw): 120V 60Hz 1PH (1.7); 220V 60Hz 1PH (0.9);
230V 50Hz 1PH (0.9); 250V 50Hz 1PH (0.9)
- Power Cord Type: 120V 60Hz; 220v 60Hz SJTOW;
230V 50Hz; 250V 50Hz H05VV-F
- Power Cord Plug End: 120V 60Hz NEMA 5-15P; 220V 60Hz NEMA 6-15P; 230V 50Hz
CEE7/7; 250V 50Hz CEE7/7 - Cord Length: 6 ft (1.8 m)
- Classification: Indoor and suitable for outdoor when installed with a Stenner Rain Roof part number MP90000
Materials of Construction:
- All Housings: Polycarbonate
- Pump Tube: Santoprene (FDA approved) or Versilon
- Check Valve Duckbill: Santoprene (FDA approved) or Pellethane
- Pump Head Rollers: Polyethylene
- Roller Bushings: Oil impregnated bronze
- Suction/Discharge Line,
and Ferrules: Polyethylene (FDA approved)
- Tube & Injection Fittings: PVC or Polypropylene (both NSF listed)
- Connecting Nuts: PVC or Polypropylene (both NSF listed)
- 3/8″ Adapter: PVC or Polypropylene (both NSF listed)
- Suction Line Strainer
and Cap: PVC or Polypropylene (both NSF listed); ceramic weight
- All Fasteners: Stainless steel
- Pump Head Latches: Polypropylene
