Stenner Plastic Water Meter Specifications:
- Accuracy: ±2% when operating between minimum and maximum flow range
- Temperature Range: 35-122°F (1.7-50°C)
- Pressure Ratings: 15-100 psi (1.0-6.9 bar)
- Maximum Current: 20mA
- Maximum Voltage: 24VAC or 24VDC
- Sensor: Reed Switch
- Cable Length: 6 ft (1.8 m)
Plastic Water Meter Materials of Construction:
- Body: Engineered reinforced plastic (nylon)
- Internal: Engineered thermoplastic
- Magnet: Alnico
Stainless Water Meter Specifications:
- Accuracy: ±1.5% max. flow rate when operating between minimum and maximum flow range
- Temperature Range: 35 -122°F (1.7 -50°C), protect the meter from freezing
- Maximum Operating Pressure: 150 psi (10.3 bar)
- Maximum Current: 20mA
- Maximum Voltage: 24VDC or VAC
- Sensor: Reed switch, dry contact type, normally open
- Cable Length: 6 ft (2 m)
Stainless Water Meter Materials of Construction:
- Body: Stainless Steel
- Internal: Engineered thermoplastic
- Magnet: Alnico
Vertical Positive Displacement (VPD) Water Meter Specifications:
- Accuracy: ±2% max. flow rate when operating between minimum and maximum flow range
- Temperature Range: 35 -122°F (1.7 -50°C), protect the meter from freezing
- Maximum Operating Pressure: 150 psi (10.3 bar)
- Maximum Current: 20mA
- Maximum Voltage: 24VDC or VAC
- Sensor: Reed switch, dry contact type, normally open
- Cable Length: 6 ft (1.8 m)
VPD Water Meter Materials of Construction:
- Body: Engineered reinforced plastic (nylon)
- Internal: Engineered thermoplastic
